技術數據-UL/CUL
|
|
等 Use Group
|
B
|
C
|
D
|
|
等 Use Group
|
300
|
-
|
300
|
|
額定電流 Rated Current [A]
|
10
|
-
|
10
|
|
接線范圍 Wire Range [AWG]
|
20~16
|
|
耐電壓 Dielectric Voltage-Withstand
|
1.6KV
|
|
|
|
技術參數-IEC
|
|
過電壓類別 Overvoltage Category
|
III
|
III
|
II
|
|
污染等 Contamination Class
|
3
|
2
|
2
|
|
額定電壓 Rated Voltage [V]
|
320
|
320
|
630
|
|
額定電流 Rated Current [A]
|
10
|
10
|
10
|
|
額定沖擊電壓 Impulse withstand voltage [KV]
|
4
|
4
|
4
|
|
導線截面積[硬/柔] Conductor cross section [mm²]
|
0.5~1.5
|
|
|
|
材料 Material
|
|
|
緣材料 Insulation Material
|
PA66
|
|
阻燃等 Flame relardant rating
|
UL94-V0
|
|
導體材料 Conductor Material
|
Copper alloy
|
|
導體表面鍍層 Plating of conductor surface
|
Sn plated
|
|
|
|
般參數 Other Data
|
|
間距/ 數 Pitch/Poles [mm]/[P]
|
5.0/1~24
|
|
剝線長度 Stripping Length [mm]
|
8-9
|
|
螺絲/扭矩 Screw/Torque(Max)[N.m]
|
/
|
|
工作溫度 Operating temperature [℃]
|
-40~+105
|
|
焊錫溫度 Soldering temperature
|
250℃/5S
|
|
引針尺寸 Pin dimensions [mm]
|
0.8*0.5
|
|
PCB板孔徑 PCB Hole Diameter [mm]
|
∅1.1
|
